Specifications:
- High pressure series
- Reversible, high performance motor
- Distinctive wave shape blade delivers a smooth and turbulence-free Airflow
- Bell mouth construction incorporated with new blade enables operation with high static pressure
- Durable powder coating ensure high rust-resistant capability
- Unique drain mechanism avoids the ingress of water and dust into the motor for excellent durability
- High performance totally enclosed motor with thermal cut-off
- Able to be used over an ambient temperature range of from -10 to 50
- Possible to install horizontally or vertically
- Voltage Single phase
- Frequency 50 Hz
- Consumption 44 W
- Air volume 1120 cmh (659 cfm)
- Max. speed 1380 rpm (min-1)
- Dimensions (W x H x D) 327 x 327 x 171 mm
- Weight 4.40 kg
